FIBER OPTIC CABLE INSTALLATIONS

Northern California Fiber Optic Cable Installation-San Francisco Bay Area Fiber Optic Cable Installations &Testing- Fiber Optic Equipment Services- OSP Fiber Cable Installations-OSP-San Francisco Data Cabling-San Francisco Data Contractors- San Francisico IT Services- San Francisco Network Integration-National Rollouts- Phone Systems- Security- San Francisco Fiber Optic Cable Installations-San Franscisco County Data Contractors-San Francisco IT Services-San Francisco County Network Integration-San Francisco County Project Mangement-San Francisco Cable Management Solutions-Call Tollfree (866) 650-DATA or click on the live support button below to talk to us

California Offices Northern CA (925) 944-0777 or tollfree (866) 650-DATA

Tampa Bay- St. Petersburg-Clearwater, Florida Offices (727) 547-2200

or click on the live support button at the top of the page to talk to us.

ATEK Communications has BICSI certified installers fully versed in fiber optic distribution designs and installations for a wide range of fiber optic network applications. We can help you integrate data and telecommunication networks over fiber effectively .

Our certified RCDD, Certified Network Specialist and BICSI Technicians work as team to bring the latest fiber optic technologies to our customers. We provide design, installation , and certifications of fiber optic cabling systems in central offices, POP sites, commercial, and residential sites

Our certified RCDDs and LAN/WAN Specialists work closely with contractors and end users to deliver the latest cabling technologies that best suit the needed applications.

All fiber optic cabling system designs are reviewed and installations quality checked by a Registered Communications Distribution Designer (RCDD). This is a professional designation of the Building Industry Consulting Services International (BICSI).

We ensure that the fiber optic cabling system design, components, and workmanship comply with the standards and practices of BICSI. These standards and practices are elaborated in the Telecommunications Distribution Methods Manual, the EIA/TIA Telecommunications Building Wiring Standard, The National Fire Protection Assn., and the National Electrical Code (NFPA-70).

Our fiber optic certifications, extensive experience on fiber optics installation, and knowledge of fiber optic technologies and standards are key factors in our successful delivery of fiber network solutions. leading fiber optic suppliers. Together we can deliver the solution that best meets your application needs, now and long term.

Our services include:

  • Design and Installation of Fiber Optic Cabling
  • Fiber Optic Termination
  • Light Interconnection Units and Fiber Shelves
  • Testing and Certifications
  • Fiber Tray and Raceway
  • Fiber Innerduct
  • Wall-mount and Freestanding Cabinets and Racks
  • Fiber Optic Fusion and Mechanical Splicing

Our certified RCDDs a nd LAN/WAN Specialists work closely with contractors and end users to deliver the latest cabling technologies that best suit the needed applications

All fiber optic cabling system designs are reviewed and installations quality checked by a Registered Communications Distribution Designer (RCDD). This is a professional designation of the Building Industry Consulting Services International (BICSI).

We ensure that the fiber optic cabling system design, components, and workmanship comply with the standards and practices of BICSI. These standards and practices are elaborated in the Telecommunications Distribution Methods Manual, the EIA/TIA Telecommunications Building Wiring Standard, The National Fire Protection Assn., and the National Electrical Code (NFPA-70).

WARRANTY

Our fiber optic cabling installations are supported by extended warranties that guarantees both end to end performance and application assurance for you. Our technicians are certified on every product installation that we design and are well trained on the industry structured cabling standard.

The specific standards of the EIA/TIA Building Telecommunications Wiring Standards are:

    · EIA/TIA-568A (Commercial Building Telecommunications Wiring Standard)
    · EIA/TIA-569 (Commercial Building Standard for Telecommunications Pathways and Spaces)
    · EIA/TIA-570 (Residential and Light Commercial Telecommunications Wiring Standard)
    · EIA/TIA-606 (Administration Standard for Telecommunications Infrastructure of Commercial Buildings)
    · EIA/TIA-607 (Commercial Building Grounding and Bonding Requirements for Telecommunications)
    · EIA/TIA-TSB-67 (Transmission Performance Specifications for Field Testing of UTP Cabling Systems)





Safety in Fiber Optic Installations All Our Technicians Are Trained In Fiber Optics Termination and Fiber Optics Safety

When most people think of safety in fiber optic installations, the first thing that comes to mind is eye damage from laser light in the fiber. They have an image of a laser burning holes in metal or perhaps burning off warts. While these images may be real for their applications, they have little relevance to most types of fiber optic communications. Eye safety is an issue, but usually not from light in the fiber. However, fiber optics installation is not without risks.

Eye Safety
Optical sources used in fiber optics, especially LEDs used in premises networks, are of much lower power levels than used for laser surgery or cutting materials. The light that exits an optical fiber is also spreading out in a cone, so the farther away from the end of the fiber your eye is, the lower the amount of power your eye receives. The infrared light in fiber optic links is at a wavelength that cannot penetrate your eye easily because it's absorbed by the water in your eyeball.
That being said, it's not a good idea to look into a fiber unless you know no source is being transmitted down it. Since the light is infrared, you can't see it, which means you cannot tell if there is light present by looking at it. Especially if you are using a microscope, which can focus the light into your eye, you should always check the fiber with a power meter before examining it.
The real issue of eye safety is getting fiber scraps into the eye. As part of the termination and splicing process, you will be continually exposed to small scraps of bare fiber, cleaved off the ends of the fibers being terminated or spliced. These scraps are very dangerous. If they get into your eyes, they are very hard to flush out and will probably lead to a trip to the emergency room at the hospital. Whenever you are working with fiber, wear safety glasses!

Bare Fiber Safety
The broken ends of fibers and scraps of fiber created during termination and splicing can be extremely dangerous. The ends are extremely sharp and can easily penetrate your skin. They invariably break off and are very hard to find and remove. Sometimes a pair of tweezers and perhaps a magnifying glass will get them out. Most of the time, you have to wait to let them infect and work themselves out, which can be painful!
Be careful when handling fibers to not stick the broken ends into your fingers. Dispose of all scraps properly. Some people keep a piece of double stick tape on the bench to stick fiber scraps onto. I prefer to use a dedicated container for all fiber scraps. In our training programs, we use the same paper containers used for takeout at the deli, in the pint size, with a lid. We put all the scraps in the container, tehn when finished, put on the lid, tape it and dispose of it later. Do not drop fiber scraps on the floor where they will stick in carpets or shoes and be carried elsewhere-like home!
Obviously do not eat or drink anywhere near the work area. Fiber scraps can get into food or drink and be swallowed. The scraps can imbed themselves in you digestive system and never be found. Doesn't sound too appetizing, does it?!

Materials Safety
Fiber optic splicing and termination use various chemical cleaners and adhesives as part of the processes. Normal handling procedures for these substances should be observed. If you are not certain of how to deal with them, ask the manufacturer for a MSDS. Always work in well-ventilated areas. Avoid skin contact as much as possible, and stop using chemicals that cause allergic reactions. Even simple isopropyl alcohol, used as a cleaner, is flammable and should be handled carefully.

Fire Safety
Note that fusion splicers use an electric arc to make splices, so care must be taken to insure no flammable gasses are contained in the space where fusion splicing is done. Splicing is never done in manholes where gasses can accumulate. The cables are brought up to the surface into a splicing trailer where all fiber work is done. Of course the splicing trailer is temperature-controlled and kept spotlessly clean to insure good splicing.
Smoking should also not be allowed around fiber optic work. The ashes from smoking contribute to the dirt problems with fibers, in addition to the chance of explosions due to the presence of combustible substances.

Electrical Safety
You might be wondering what electrical safety has to do with fiber optics. Well fiber cables are often installed around electrical cables. Electricians are well-trained in electrical safety, but some fiber optic installers are not. We've heard rumors of fiber installers being shocked when working around electrical cables, but know that two fiber installers were killed when working on aerial cables because we heard about it from OSHA.
These two installers were installing all-dielectric self-supporting aerial cables on poles. The hangers, however, were metal and over six feet long. Both had attached the hangers to the poles, then when installing the fiber cables had rotated the hangers enough to contact high-voltage lines.
So even if the fiber is not conductive, fiber hardware can conduct electricity or the installer can come in contact with live electrical wires when working in proximity to AC power.

Fiber Optic Installation Safety Rules:

1. Keep all food and beverages out of the work area. If fiber particles are ingested they can cause internal hemorrhaging
2. Wear disposable aprons to minimize fiber particles on your clothing. Fiber particles on your clothing can later get into food, drinks, and/or be ingested by other means.
3. Always wear safety glasses with side shields and protective gloves. Treat fiber optic splinters the sarne as you would glass splinters.
4. Never look directly into the end of fiber cables until you are positive that there is no light source at the other end. Use a fiber optic power meter to make certain the fiber is dark. When using an optical tracer or continuity checker, look at the fiber from an angle at least 6 inches away from your eye to determine if the visible light is present..
5. Only work in well ventilated areas.
6. Contact wearers must not handle their lenses until they have thoroughly washed their hands.
7. Do not touch your eyes while working with fiber optic systems until they have been thoroughly washed.
8. Keep all combustible materials safely away from the curing ovens.
9. Put all cut fiber pieces in a safe place.
10. Thoroughly clean your work area when you are done.
11. Do not smoke while working with fiber optic systems.

BRIEF OVER VIEW OF FIBER OPTIC CABLE ADVANTAGES OVER COPPER:

• SPEED: Fiber optic networks operate at high speeds - up into the gigabits
• BANDWIDTH: large carrying capacity
• DISTANCE: Signals can be transmitted further without needing to be "refreshed" or strengthened.
• RESISTANCE: Greater resistance to electromagnetic noise such as radios, motors or other nearby cables.
• MAINTENANCE: Fiber optic cables costs much less to maintain.


In recent years it has become apparent that fiber-optics are steadily replacing copper wire as an appropriate means of communication signal transmission. They span the long distances between local phone systems as well as providing the backbone for many network systems. Other system users include cable television services, university campuses, office buildings, industrial plants, and electric utility companies.

A fiber-optic system is similar to the copper wire system that fiber-optics is replacing. The difference is that fiber-optics use light pulses to transmit information down fiber lines instead of using electronic pulses to transmit information down copper lines. Looking at the components in a fiber-optic chain will give a better understanding of how the system works in conjunction with wire based systems.

At one end of the system is a transmitter. This is the place of origin for information coming on to fiber-optic lines. The transmitter accepts coded electronic pulse information coming from copper wire. It then processes and translates that information into equivalently coded light pulses. A light-emitting diode (LED) or an injection-laser diode (ILD) can be used for generating the light pulses. Using a lens, the light pulses are funneled into the fiber-optic medium where they transmit themselves down the line.

Think of a fiber cable in terms of very long cardboard roll (from the inside roll of paper towel) that is coated with a mirror.
If you shine a flashlight in one you can see light at the far end - even if bent the roll around a corner.

Light pulses move easily down the fiber-optic line because of a principle known as total internal reflection. "This principle of total internal reflection states that when the angle of incidence exceeds a critical value, light cannot get out of the glass; instead, the light bounces back in. When this principle is applied to the construction of the fiber-optic strand, it is possible to transmit information down fiber lines in the form of light pulses.Fiber optic cable functions as a "light guide," guiding the light introduced at one end of the cable through to the other end. The light source can either be a light-emitting diode (LED)) or a laser.

The light source is pulsed on and off, and a light-sensitive receiver on the other end of the cable converts the pulses back into the digital ones and zeros of the original signal.

Even laser light shining through a fiber optic cable is subject to loss of strength, primarily through dispersion and scattering of the light, within the cable itself. The faster the laser fluctuates, the greater the risk of dispersion. Light strengtheners, called repeaters, may be necessary to refresh the signal in certain applications.

While fiber optic cable itself has become cheaper over time - a equivalent length of copper cable cost less per foot but not in capacity. Fiber optic cable connectors and the equipment needed to install them are still more expensive than their copper counterparts.

The use of fiber-optics was generally not available until 1970 when Corning Glass Works was able to produce a fiber with a loss of 20 dB/km. It was recognized that optical fiber would be feasible for telecommunication transmission only if glass could be developed so pure that attenuation would be 20dB/km or less. That is, 1% of the light would remain after traveling 1 km. Today's optical fiber attenuation ranges from 0.5dB/km to 1000dB/km depending on the optical fiber used. Attenuation limits are based on intended application.

The applications of optical fiber communications have increased at a rapid rate, since the first commercial installation of a fiber-optic system in 1977. Telephone companies began early on, replacing their old copper wire systems with optical fiber lines. Today's telephone companies use optical fiber throughout their system as the backbone architecture and as the long-distance connection between city phone systems.

Cable television companies have also began integrating fiber-optics into their cable systems. The trunk lines that connect central offices have generally been replaced with optical fiber. Some providers have begun experimenting with fiber to the curb using a fiber/coaxial hybrid. Such a hybrid allows for the integration of fiber and coaxial at a neighborhood location. This location, called a node, would provide the optical receiver that converts the light impulses back to electronic signals. The signals could then be fed to individual homes via coaxial cable.

Local Area Networks (LAN) is a collective group of computers, or computer systems, connected to each other allowing for shared program software or data bases. Colleges, universities, office buildings, and industrial plants, just to name a few, all make use of optical fiber within their LAN systems.

Power companies are an emerging group that have begun to utilize fiber-optics in their communication systems. Most power utilities already have fiber-optic communication systems in use for monitoring their power grid systems.

Single Mode cable is a single stand of glass fiber with a diameter of 8.3 to 10 microns that has one mode of transmission. Single Mode Fiber with a relatively narrow diameter, through which only one mode will propagate typically 1310 or 1550nm. Carries higher bandwidth than multimode fiber, but requires a light source with a narrow spectral width. Synonyms mono-mode optical fiber, single-mode fiber, single-mode optical waveguide, uni-mode fiber.

Single-mode fiber gives you a higher transmission rate and up to 50 times more distance than multimode, but it also costs more. Single-mode fiber has a much smaller core than multimode. The small core and single light-wave virtually eliminate any distortion that could result from overlapping light pulses, providing the least signal attenuation and the highest transmission speeds of any fiber cable type.

Single-mode optical fiber is an optical fiber in which only the lowest order bound mode can propagate at the wavelength of interest typically 1300 to 1320nm.

Multimode cable is made of of glass fibers, with a common diameters in the 50-to-100 micron range for the light carry component (the most common size is 62.5). POF is a newer plastic-based cable which promises performance similar to glass cable on very short runs, but at a lower cost.

Multimode fiber gives you high bandwidth at high speeds over medium distances. Light waves are dispersed into numerous paths, or modes, as they travel through the cable's core typically 850 or 1300nm. Typical multimode fiber core diameters are 50, 62.5, and 100 micrometers. However, in long cable runs (greater than 3000 feet [914.4 ml), multiple paths of light can cause signal distortion at the receiving end, resulting in an unclear and incomplete data transmission.


Fiber Optic Testing Equipment

ATEK also offers fiber opic testing. ATEK can assist your organization whether you need central office testing or outside plant singlemode splicing. For example, there are two methods to measure test loss, single-ended loss and double-ended loss. Single-ended loss works by using only the launch cable while the double-ended loss works by using a received cable attached to the meter also. All are technicians are certified by the manufacturers we represent to perform the tests.
